by Patchesroy Mon Nov 17, 2014 6:09 amHey guys. Finally got the van off the lift and ready to roll. So when I bought the van the guy had it hot wired from the coil and starter. We'll I'm trying to get it turn key again but I could use some help. Also I'm looking for a manual online for it
3 posters
65 g10 manual
Patchesroy- Number of posts : 43
Location : Valley lee maryland
Registration date : 2014-05-25
Vantasia- Number of posts : 1412
Location : New Jersey
Age : 70
Registration date : 2013-08-18
You can get the shop manual on eBay used or new, plenty there.
http://www.ebay.com/itm/1964-1965-1966-Chevy-Van-Repair-Shop-Manual-G10-Supplement-Chevrolet-/361021955588?pt=Motors_Manuals_Literature&hash=item540e95de04&vxp=mtr
There is a CD version but never seen anything online you can look at, only the specs at GM Heritage Center. The wiring diagrams are here on this forum under archives or someone can post for you to print. The manual is called the Van Supplement to the standard truck manual for the same years and shows everything about the van body, mechanicals, brakes and electrical. Doesn't have much on the engine as that would be in the regular manual.
http://www.ebay.com/itm/1964-1965-1966-Chevy-Van-Repair-Shop-Manual-G10-Supplement-Chevrolet-/361021955588?pt=Motors_Manuals_Literature&hash=item540e95de04&vxp=mtr
There is a CD version but never seen anything online you can look at, only the specs at GM Heritage Center. The wiring diagrams are here on this forum under archives or someone can post for you to print. The manual is called the Van Supplement to the standard truck manual for the same years and shows everything about the van body, mechanicals, brakes and electrical. Doesn't have much on the engine as that would be in the regular manual.
donivan65- Governor
- Number of posts : 12220
Location : San Diego, California
Registration date : 2008-05-12
These are the books,,,,,,
as for the ignition wire,,,,,,,the Pink wire runs from the ignition switch to the connector in the Doghouse right next to the carburetor,,,,,,,it changes to a White/Orange/Purple cloth covered resistance wire as it leaves the connector.....this cuts the voltage down to the coil,,,,,,,,as that wire goes towards the Positive side of the coil, it picks up a hitch hiker Yellow wire which is the 12 volt boost from the R terminal on the starter solenoid,,,,,,and usually the Yellow wire goes to the Positive side of the coil,,,,,,so the resistor wire is connected to the Yellow wire,,,,,,could be soldered to it,,,,,both connected on the R terminal of the starter solenoid or both on the Positive post on the coil,,,,
as for the ignition wire,,,,,,,the Pink wire runs from the ignition switch to the connector in the Doghouse right next to the carburetor,,,,,,,it changes to a White/Orange/Purple cloth covered resistance wire as it leaves the connector.....this cuts the voltage down to the coil,,,,,,,,as that wire goes towards the Positive side of the coil, it picks up a hitch hiker Yellow wire which is the 12 volt boost from the R terminal on the starter solenoid,,,,,,and usually the Yellow wire goes to the Positive side of the coil,,,,,,so the resistor wire is connected to the Yellow wire,,,,,,could be soldered to it,,,,,both connected on the R terminal of the starter solenoid or both on the Positive post on the coil,,,,
|
|
|
